Elite Series AOBEAD UV inkjet digital printing machine DPIM-330

Elite Series AOBEAD UV inkjet digital printing machine DPIM-330

Performance Characteristics

1. Automatic printhead cleaning function, one-click to open the automatic cleaning.
2. Excellent quality output, applying multi-level ink droplet technology to optimize the printing fineness of labels, ultra-realistic simulation of spot-color full-color output.
3. Variable data high-speed printing and reading code recognition supported, easily realizing variable data printing such as one-dimensional code, two-dimensional code, serial number and dot matrix code.
4. Adding a post-press inspection quality control system simplifies redundant operations, makes it easy to understand, and improves job processing speed.

Case video

Elite Series AOBEAD UV inkjet digital printing machine DPIM-330
Elite Series AOBEAD UV inkjet digital printing machine DPIM-330
Specifications
Maximum resolution
1200×600dpi
Spraying speed
30~60m
Material width range
20~330mm
Material thickness size
0.02~0.5mm
Ink type
UV ink
Ink configuration
CMYK four-color as standard (white is optional)
Maximum detection accuracy
0.02mm²
Relative humidity
40%-60%(no condensation)
Ambient temperature
20℃-26℃
Power supply requirement
AC380V/50Hz/20A
Equipment weight
4000KG
Equipment size
4200mm×1600mm×1820mm

Applicable industries

Applicable materials
Film: PET/PVC/PP/PE/BOPP and other films
Paper: synthetic paper, coated paper and aluminum foil and other special materials

Applicable label industries
